Rexroth A7VKO axial hydraulic variable pump — technical brief for OEM and system designers

The Rexroth A7VKO hydraulic pump (English keyword: Rexroth A7VKO axial variable pump) family delivers compact, high-efficiency axial-piston performance for mobile and industrial hydraulic systems. Common frame sizes include A7VKO012, A7VKO028, A7VKO055 and A7VKO107, each built for continuous operation in heavy-duty environments. BAOLILAI produces OEM-compatible units with factory testing; full PDF datasheets and CAD are available at www.baolilai-pump.com and by request at www.baolilai-pump.com/contact_us/. Each pump is supplied with a one-year warranty.

Copyable technical parameter table

Model	Displacement (cc/rev)	Speed range (rpm)	Rated pressure (bar)	Warranty
A7VKO012	12	1500–1800	400–450	1 year
A7VKO028	28	1500–1800	400–450	1 year
A7VKO055	55	1500–1800	400–450	1 year
A7VKO107	107	1500–1800	400–450	1 year

Design highlights
• Bent-axis axial piston architecture for high volumetric efficiency and low internal leakage.
• Hardened rotating group, precision pistons and optimized swashplate reduce wear and heat generation.
• Reinforced housings, heavy-duty bearings and optional explosion-resistant variants for hazardous zones.
• Surface treatments and special seals available for marine, mining or corrosive environments.
• Compact footprint and multiple mounting/shaft options simplify retrofit into planetary gearboxes and OEM drives.

Application scenarios and OEM examples
The A7VKO series is specified where compact, efficient pumping is required for continuous service:

• Agricultural machinery: Primary and implement pumps on large tractors and combine harvesters (example OEM sites: www.deere.com, www.agrifac.com). Models such as the A7VKO012 and A7VKO028 are well suited to implement circuits and steering control.
• Construction equipment: Main pump and auxiliary pump duties on excavators and pavers—suitable for medium-class excavators and compact wheel loaders (example OEM sites: www.cat.com, www.jcb.com). The A7VKO055 is a common choice where higher flow is needed.
• Mining and quarrying: High-durability pumps for shuttle conveyors, drilling rigs and support equipment, where A7VKO107 delivers sustained flow at high pressure (example OEM sites: www.komatsu.com, www.liebherr.com).
• Engineering & industrial systems: Hydraulic presses, marine winches and material-handling cranes benefit from the A7VKO’s stable pressure control and explosion-proof options (example OEM sites: www.konecranes.com, www.electrohydraulicspecialist.com).

System integration guidance

1. Calculate target rpm: rpm ≈ (system flow L/min × 1000) ÷ displacement (cc/rev), then allow margin for volumetric efficiency.
2. Maintain hydraulic fluid cleanliness per OEM ISO targets; fine filtration extends service life of pistons and swashplate.
3. Install oil coolers for sustained high-power cycles; monitor oil temperature and viscosity.
4. Use accumulators or pilot-operated dampers to protect against pressure spikes and transient loads.
5. Confirm shaft/mounting selection at order to avoid retrofit delays.

FAQ

Q1: Which A7VKO model is best for a medium excavator?
A1: For medium excavators requiring a balance of flow and pressure, A7VKO055 is often chosen; final selection should match required actuator speeds and system flow.

Q2: Can A7VKO pumps be used in closed-loop hydrostatic drives?
A2: Yes—A7VKO units integrate into closed-loop systems when paired with appropriate charge pumps, relief valves and control electronics.

Q3: Are explosion-proof options available?
A3: Yes. BAOLILAI offers explosion-resistant housings and special seals for hazardous environments; specify at purchase.

Q4: Where to download datasheets and request support?
A4: Visit www.baolilai-pump.com or request PDFs at www.baolilai-pump.com/contact_us/.

Conclusion
The Rexroth A7VKO axial variable piston pump series (A7VKO012, A7VKO028, A7VKO055, A7VKO107) provides reliable, high-pressure pumping for a wide range of industrial and mobile applications. With robust construction, environmental options and BAOLILAI’s one-year warranty, these pumps meet OEM requirements for durability and performance.

Order Number	Internal Number
R902186115	A7VKO028MA/10MRSL4P550-0
R902047310	A7VKO28MA/63R-XPB01
R902063864	A7VKO28MA/63R-XPB01
R902182480	A7VKO012MA/10MLSK4P350-027412.0001
R902186228	A7VKO012MA/10MRSK4P35A-027412.0001
R902186230	A7VKO028MA/10MRSL4P55A-027416.0026
R902186232	A7VKO028MA/10MLSLGP55A250-01
R902194075	A7VKO012MA/10MRSK4P350-0 27412.0001
R902194077	A7VKO028MA/10MRSL4P550-0 27416.0026
R902196685	A7VKO012MA/10MRSK4P350-027412.0001
R902196688	A7VKO028MA/10MRSL4P550-0 27416.0026
R902200079	A7VKO055MA/10MRSMSP650000-0
R902202301	A7VKO055MG/10MRSMSP65000-0’542627’*EW
R902203773	A7VKO107MA/10MRSPSP950000-0
R902232534	A7VKO055MA/10MRSMSP65A250-0
R902233423	A7VKO028MA/10MRSLGP55A200-0
R902237026	A7VKO107MA10MRSPSP95A150-0 274.25.00.02
R902242619	A7VKO012MA/10MRSKGP350000-S 27412.0002
R902247373	A7VKO012MA/10MRSKGP35A250-0
R902247453	A7VKO028MA/10MLSLGP550000-0
R902250891	A7VKO005MA/10MRSKGP350000-0C *EW*
R902253592	A7VKO012MA/10MRSKGP35A250-0
R902253695	A7VKO107MA/10MRSPSP95A130-0
R902242642	A7VKO028MA/10MRSLGP55000-S 27416.0027
R902255778	A7VKO028MA/10MRSLGP550000-0
R902255853	A7VKO055MA/10MRSMSP65A200-0
R902269966	A7VKO028MA/10MRSLGP55A250-0
R902255777	A7VKO012MA/10MRSKGP350000-0
R927231119	A7VKO012MA/10MRSK4P350-0
R902182161	A7VKO012MA/10MRSKGP350000-0
R902206538	A7VKO107MA/10MRSPSP950000-0
R902206543	A7VKO055MA/10MRSMSP650000-0
R902270055	A7VKO028MA/10MRSLGP550000-S 27416.0026
