Rexroth A2VK Hydraulic Pump — robust axial-piston power for demanding systems
Visit technical pages: www.baolilai-pump.com — request A2VK PDF datasheets: www.baolilai-pump.com/contact_us/

Introduction
The Rexroth A2VK hydraulic pump series is a proven bent-axis axial-piston platform engineered for high reliability, serviceability and energy efficiency in mobile and industrial hydraulics. Available in common frame sizes such as A2VK12, A2VK28, A2VK55 and A2VK107, the family covers low- to high-flow requirements while supporting continuous operation across 735–1800 rpm and rated system pressures of 250–315 bar. BAOLILAI supplies OEM-compatible units with factory testing and a one-year warranty; request complete PDFs at www.baolilai-pump.com/contact_us/.

Copyable technical parameter table

Model	Displacement (cc/rev)	Recommended Speed (rpm)	Rated Pressure (bar)	Warranty
A2VK12	12	735–1800	250–315	1 year
A2VK28	28	735–1800	250–315	1 year
A2VK55	55	735–1800	250–315	1 year
A2VK107	107	735–1800	250–315	1 year

Design highlights — why A2VK suits modern machines
• Bent-axis geometry delivers high volumetric efficiency and compact power density.
• Low leakage at high pressure reduces heat build-up, improving thermal stability in continuous-duty circuits.
• Reinforced housings and heavy-duty bearings provide resistance to pressure transients and mechanical shock.
• Options for explosion-proof variants, corrosion coatings and special sealing enable safe operation in hazardous or marine environments.

Typical machine integrations (examples & OEM sites)
The A2VK series is widely used as main and auxiliary pumps across agriculture, construction, engineering and mining systems. Sample integrations:

• Agricultural tractors and combine drives — large implements and hydrostatic transmissions (example OEM sites: www.deere.com, www.caseih.com).
• Excavators and wheeled loaders — swing, travel and implement circuits that require continuous high flow (example OEM sites: www.cat.com, www.volvoce.com).
• Mining shovels and haul trucks — high-duty, high-pressure hydraulics where durability is critical (example OEM sites: www.komatsu.com, www.liebherr.com).
• Industrial presses and marine deck equipment — closed-loop drive systems benefiting from A2VK’s compact package (example OEM sites: www.jcb.com, www.doosanequipment.com).

System integration checklist (practical guidance)

1. Match pump displacement to system flow and desired shaft speed — calculate target rpm = (system flow L/min × 1000) ÷ displacement cc/rev, and allow margin for efficiency losses.
2. Filtration & cleanliness — maintain ISO cleanliness per OEM recommendations; use fine filtration (β10 / β16) to protect piston group and valves.
3. Thermal management — add coolers for sustained high-power cycles; monitor oil temperature.
4. Transient protection — fit accumulators or pressure dampers to mitigate spikes; specify reinforced option where shock loads occur.
5. Installation — ensure correct coupling alignment and mounting torque to avoid shaft and bearing overload.

Durability & safety features
A2VK pumps can be specified with explosion-proof housings and high-temperature seal materials for use in hazardous zones or extreme climates. Reinforced porting and hardened swash plates increase resistance to abrasive contamination and extend service intervals. BAOLILAI provides custom surface treatments and protective coatings for offshore, desert or corrosive environments.

FAQ

Q1 — What operating pressures and speeds are typical for A2VK pumps?
A1 — The A2VK family is commonly applied at 250–315 bar and speeds within 735–1800 rpm; exact limits depend on model and OEM configuration.

Q2 — How do I choose between A2VK12 and A2VK107?
A2 — Select by required displacement (flow) and torque. Use A2VK12/A2VK28 for lower-flow auxiliary drives, A2VK55/A2VK107 for primary pumps on larger machines.

Q3 — Are explosion-proof and corrosion options available?
A3 — Yes. BAOLILAI supplies explosion-protected variants and special coatings; specify environmental options at the time of order.

Q4 — Where can I download CAD, curves and PDF?
A4 — Request full technical files and datasheets at www.baolilai-pump.com/contact_us/ or browse product listings at www.baolilai-pump.com.

Conclusion
The Rexroth A2VK hydraulic pump range (A2VK12, A2VK28, A2VK55, A2VK107) delivers efficient, compact hydraulic power for modern OEM systems. With proven pressure resilience, explosion-proof options and global OEM compatibility, these pumps are suitable for the toughest agricultural, construction, mining and industrial applications. For specification support and PDF downloads, visit www.baolilai-pump.com and request datasheets at www.baolilai-pump.com/contact_us/

Order Number	Internal Number
R902060359	A2VK107GEGR1G0PE1-SO6
R909603618	A2VK107GEOR1G0PE1-SO6
R902018193	A2VK107GEOR1G1PE1-SO4
R909081581	A2VK107MA/GE
R902067668	A2VK107MA/GE-LINKSLAUF
R909604857	A2VK107MAGR1G0PE1-SO2
R902043533	A2VK107MAGR1G1PE1-SO
R902043534	A2VK107MAGR1G1PE2-SO
R902073999	A2VK107MAOL1G0PE1-SO
R902067669	A2VK107MAOL1G0PE2-SO
R902080654	A2VK107MAOL1G0PE2-SO2
R909604865	A2VK107MAOR1G0PE1-SO
R909448595	A2VK107MAOR1G0PE1-SO2
R909605535	A2VK107MAOR1G0PE1-SO7
R909604864	A2VK107MAOR1G0PE2-SO
R902084124	A2VK107MAOR1G0PE2-SO2
R909605536	A2VK107MAOR1G0PE2-SO7
R902028557	A2VK107MAOR1G1PE1-SO2
R909604914	A2VK107MAOR1G1PE2
R902028558	A2VK107MAOR1G1PE2-SO2
R909081906	A2VK107OVGR1G00P
R909442660	A2VK107OVGR1G00P
R902080653	A2VK107OVOL1G00P
R909442661	A2VK107OVOR1G00P
R902033112	A2VK12GEGL4G1PE1-SO
R909605128	A2VK12GEGR4G0PE1-SO
R902067774	A2VK12GEGR4G0PE1-SO16
R902088528	A2VK12GEGR4G0PE1-SO6
R902035132	A2VK12GEGW4G0PE1-SO
R902054201	A2VK12GEGW4G0PE1-SO6
R909605414	A2VK12GEOR4G0PE1-SO
R909447718	A2VK12GEOR4G0PE1-SO6
R902000445	A2VK12GEOR4G0PE2-SO6
R902014085	A2VK12GEOR4G1PE1-SO10
R902065599	A2VK12GL4G0PE-SO
R902054202	A2VK12GW4G0PE-SO
R902067773	A2VK12GW4G0PE-SO11
R902047231	A2VK12MAGL4G0PE1-SO2
R902031610	A2VK12MAGL4G0PE2
R902065835	A2VK12MAGL4G0PE2-SO
R902045259	A2VK12MAGL4G1PE2-SO
R902065600	A2VK12MAGL4G1PE2-SO2
R909604765	A2VK12MAGR4G0PE1
R909604763	A2VK12MAGR4G0PE1-SO
R909605243	A2VK12MAGR4G0PE1-SO10
R902034181	A2VK12MAGR4G0PE1-SO11
R909447193	A2VK12MAGR4G0PE1-SO2
R909605114	A2VK12MAGR4G0PE1-SO9
R909604912	A2VK12MAGR4G0PE2
R909604986	A2VK12MAGR4G0PE2-SO
R902036692	A2VK12MAGR4G0PE2-SO10
R902047230	A2VK12MAGR4G0PE2-SO2
R909605115	A2VK12MAGR4G0PE2-SO9
R909604654	A2VK12MAGR4G1PE1
R902078760	A2VK12MAGR4G1PE1-SO11
R902004352	A2VK12MAGR4G1PE1-SO2
R909448100	A2VK12MAGR4G1PE1-SO3
R909603406	A2VK12MAGR4G1PE1-SO8
R909604655	A2VK12MAGR4G1PE2
R909604764	A2VK12MAGR4G1PE2-SO
R902027140	A2VK12MAGR4G1PE2-SO2
R909603682	A2VK12MAGR4G1PE2-SO8
R902065720	A2VK12MAOL4G0PE1-SO
R902073985	A2VK12MAOL4G0PE1-SO2
R902054915	A2VK12MAOL4G0PE2
R902052393	A2VK12MAOL4G0PE2-SO
R902052372	A2VK12MAOL4G0PE2-SO2
R902060110	A2VK12MAOL4G1PE1-SO
R902060108	A2VK12MAOL4G1PE1-SO2
R902054827	A2VK12MAOL4G1PE2-SO
R902084061	A2VK12MAOL4G1PE2-SO2
R909604353	A2VK12MAOR4G0PE1
R909604506	A2VK12MAOR4G0PE1-SO
R909604755	A2VK12MAOR4G0PE1-SO1
R909604834	A2VK12MAOR4G0PE1-SO10
R909603730	A2VK12MAOR4G0PE1-SO11
R909603866	A2VK12MAOR4G0PE1-SO12
R909447172	A2VK12MAOR4G0PE1-SO2
R909446008	A2VK12MAOR4G0PE1-SO3
R909447017	A2VK12MAOR4G0PE1-SO7
R909604952	A2VK12MAOR4G0PE1-SO9
R909604913	A2VK12MAOR4G0PE2
R909604987	A2VK12MAOR4G0PE2-SO
R902024765	A2VK12MAOR4G0PE2-SO2
R909447014	A2VK12MAOR4G0PE2-SO7
R909604830	A2VK12MAOR4G1PE1
R909604348	A2VK12MAOR4G1PE1-SO
R909605307	A2VK12MAOR4G1PE1-SO12
R902004079	A2VK12MAOR4G1PE1-SO2
R902086544	A2VK12MAOR4G1PE1-SO7
R909603462	A2VK12MAOR4G1PE1-SO8
R909604829	A2VK12MAOR4G1PE2
R909604352	A2VK12MAOR4G1PE2-SO
R909605308	A2VK12MAOR4G1PE2-SO12
R902004081	A2VK12MAOR4G1PE2-SO2
R902080731	A2VK12MAOR4G1PE2-SO7
R909603350	A2VK12MAOR4G1PE2-SO8
R909603364	A2VK12MAOR4GOPE1-SO8
R902065834	A2VK12OVGL4OOP
R902070571	A2VK12OVGW4G00P-SO
R902052373	A2VK12OVOL4G00P-SO
R902052394	A2VK12OVOL4G00P-SO
R902054914	A2VK12OVOL4G00P-SO
R909081716	A2VK12OVOR4G00P-SO
R909442492	A2VK12OVOR4G00P-SO2
R902067940	A2VK12-RECHTSLAUF
R902052255	A2VK28GEGL1G0PE2-SO6
R902086611	A2VK28GEGR1G0PE1-SO16
R902033114	A2VK28GEGR1G0PE1-SO6
R909604012	A2VK28GEGR1G1PE2-SO5
R902014299	A2VK28GEGW1G0PE1-SO
R909605415	A2VK28GEOR1G0PE1-SO
R909447432	A2VK28GEOR1G0PE1-SO6
R902035185	A2VK28GEOR1G0PE1-SO61
R902009694	A2VK28GEOR1G0PE2-SO7
R902014086	A2VK28GEOR1G1PE1-SO10
R909604727	A2VK28GEOR1G1PE2-SO5
R902073966	A2VK28MAGL1G0PE1-SO
R902067594	A2VK28MAGL1G0PE2-SO
R909604767	A2VK28MAGR1G0PE1
R909604988	A2VK28MAGR1G0PE1-SO
R909604837	A2VK28MAGR1G0PE1-SO10
R909447194	A2VK28MAGR1G0PE1-SO2
R909603547	A2VK28MAGR1G0PE1-SO8
R909604891	A2VK28MAGR1G0PE1-SO9
R902063697	A2VK28MAGR1G0PE2-SO2
R909604892	A2VK28MAGR1G0PE2-SO9
R909604656	A2VK28MAGR1G1PE1
R909604766	A2VK28MAGR1G1PE1-SO
R902004353	A2VK28MAGR1G1PE1-SO2
R909604657	A2VK28MAGR1G1PE2
R909604658	A2VK28MAGR1G1PE2-SO
R902027141	A2VK28MAGR1G1PE2-SO2
R902036628	A2VK28MAGW1G0PE1-SO
R902031665	A2VK28MAOL1G0PE1-SO
R902101233	A2VK28MAOL1G0PE1-SO2
R902054241	A2VK28MAOL1G0PE2
R902036991	A2VK28MAOL1G0PE2-SO
R902052369	A2VK28MAOL1G0PE2-SO2
R902060112	A2VK28MAOL1G1PE1-SO
R902060113	A2VK28MAOL1G1PE1-SO2
R902084059	A2VK28MAOL1G1PE2-SO2
R909604337	A2VK28MAOR1G0PE1
R902092011	A2VK28MAOR1G0PE1-ESO2
R909604391	A2VK28MAOR1G0PE1-SO
R909605252	A2VK28MAOR1G0PE1-SO10
R909603727	A2VK28MAOR1G0PE1-SO11
R909605335	A2VK28MAOR1G0PE1-SO12
R909446351	A2VK28MAOR1G0PE1-SO2
R909446009	A2VK28MAOR1G0PE1-SO3
R909447064	A2VK28MAOR1G0PE1-SO7
R909604989	A2VK28MAOR1G0PE2-SO
R902028554	A2VK28MAOR1G0PE2-SO2
R909446046	A2VK28MAOR1G0PE2-SO3
R909447063	A2VK28MAOR1G0PE2-SO7
R909604911	A2VK28MAOR1G1PE1
R909604336	A2VK28MAOR1G1PE1-SO
R902004354	A2VK28MAOR1G1PE1-SO2
R902024706	A2VK28MAOR1G1PE1-SO7
R909604769	A2VK28MAOR1G1PE1-SO8
R909604446	A2VK28MAOR1G1PE2-SO
R909605336	A2VK28MAOR1G1PE2-SO12
R902009895	A2VK28MAOR1G1PE2-SO2
R902024707	A2VK28MAOR1G1PE2-SO7
R909604768	A2VK28MAOR1G1PE2-SO8
R902067593	A2VK28OVGL1G00P-SO
R902052254	A2VK28OVGL1G00P-SO2
R909065157	A2VK28OVGR1G00P
R909076531	A2VK28OVGR1G00P
R909417793	A2VK28OVGR1G00P
R909081903	A2VK28OVGR1G00P-SO
R909604836	A2VK28OVGR1G00P-SO10
R902086610	A2VK28OVGR1G00P-SO12
R909442566	A2VK28OVGR1G00P-SO2
R902036627	A2VK28OVGW1G00P-SO
R902070940	A2VK28OVGW1G00P-SO
R902054242	A2VK28OVOL1G00P
R902070941	A2VK28OVOL1G00P-SO
R902060111	A2VK28OVOL1G00P-SO
R902052370	A2VK28OVOL1G00P-SO2
R909063496	A2VK28OVOR1G00P
R909416620	A2VK28OVOR1G00P
R909081904	A2VK28OVOR1G00P-SO
R909442567	A2VK28OVOR1G00P-SO2
R902035184	A2VK28OVOR1G00P-SO61
R909605251	A2VK28OVOR1G0PE-SO9
R909605327	A2VK28OVOR1GPE-SO12
R902000253	A2VK55GEOR1G0PE1-SO
R909447290	A2VK55GEOR1G0PE1-SO6
R902000252	A2VK55GEOR1G0PE2-SO
R909604803	A2VK55GEOR1G1PE2-SO5
R902043851	A2VK55MAGL1G0PE1-SO2
R902000250	A2VK55MAGR1G0PE1
R909604844	A2VK55MAGR1G0PE1-SO10
R909604508	A2VK55MAGR1G0PE2
R902000251	A2VK55MAGR1G0PE2-SO
R902038629	A2VK55MAGR1G0PE2-SO2
R902024879	A2VK55MAGR1G1PE1
R909604725	A2VK55MAGR1G1PE1-SO
R902024800	A2VK55MAGR1G1PE1-SO10
R902004355	A2VK55MAGR1G1PE1-SO2
R902024881	A2VK55MAGR1G1PE2
R909604726	A2VK55MAGR1G1PE2-SO
R902047068	A2VK55MAGR1G1PE2-SO2
R902054700	A2VK55MAOL1G0PE2
R902057443	A2VK55MAOL1G0PE2-SO
R902080651	A2VK55MAOL1G0PE2-SO2
R909604387	A2VK55MAOR1G0PE1-SO
R909446352	A2VK55MAOR1G0PE1-SO2
R909603596	A2VK55MAOR1G0PE1-SO7
R909604386	A2VK55MAOR1G0PE2-SO
R902042042	A2VK55MAOR1G0PE2-SO2
R909603595	A2VK55MAOR1G0PE2-SO7
R909604729	A2VK55MAOR1G1PE1-SO
R902021875	A2VK55MAOR1G1PE1-SO10
R909604730	A2VK55MAOR1G1PE2-SO
R902052376	A2VK55OVGL1G00P-SO
R902070943	A2VK55OVGL1G00P-SO2
R909070964	A2VK55OVGR1G00P
R909081905	A2VK55OVGR1G00P-SO
R909604841	A2VK55OVGR1G00P-SO10
R902054701	A2VK55OVOL1G00P
R902057442	A2VK55OVOL1G00P-SO
R902080650	A2VK55OVOL1G00P-SO2
R909064723	A2VK55OVOR1G00P
R909081600	A2VK55OVOR1G00P-SO
R902021874	A2VK55OVOR1G00P-SO10
R909442588	A2VK55OVOR1G00P-SO2
