Sauer Danfoss 90-M-042 axial piston motor 90M042 hydraulic motors
Sauer Danfoss 90-M-042 axial piston motor 90M042 hydraulic motors

- Product Details
Sauer Danfoss 90-M-042 axial piston motor 90-M-042-NC-0-N-8-N-0-C2-N-00-NNN-00-00-00 hydraulic motors for John Deere harvester
Sauer Danfoss 90M042 Hydraulic Motor: 42cc Precision Drive for Mobile Equipment
Engineered for agricultural harvesters and forestry cranes, the 90M042 hydraulic motor delivers 42cc displacement with NC-series electronic control. This variable-displacement axial piston motor generates 320 Nm torque at 420 bar continuous pressure, enabling precise speed regulation for conveyor drives and winch systems. Hardened components withstand crop residue and wood debris while maintaining 95% mechanical efficiency across 3100–4200 RPM.
The C2-rated noise emission stays below 80 dB(A) for operator comfort, with zero-leakage shaft seals ensuring 20,000+ service hours in dusty field conditions. Compatibility with biodegradable hydraulic fluids (ISO VG 46) meets environmental regulations. Integrated pressure cut-off function prevents overloads during shock loads. Designed for John Deere S700 combines and Ponsse harvesters.
Access OEM integration guidelines and performance curves: https://www.baolilai-pump.com/.









Order Number | Internal Number | Nameplate Model |
515499 | 90-M-042-NC-0-N-8-N-0-C2-N-00-NNN-00-00-00 | 90M042NC0N8N0C2N00NNN000000 |
762708 | 90-M-042-NC-0-N-8-N-0-C2-W-00-NNN-00-00-E6 | 90M042NC0N8N0C2W00NNN0000E6 |
511239 | 90-M-042-NC-0-N-8-N-0-C3-N-00-NNN-00-00-00 | 90M042NC0N8N0C3N00NNN000000 |
516558 | 90-M-042-NC-0-N-8-N-0-C3-W-00-EFA-00-00-F3 | 90M042NC0N8N0C3W00EFA0000F3 |
701734 | 90-M-042-NC-0-N-8-N-0-C3-W-00-NNN-00-00-E4 | 90M042NC0N8N0C3W00NNN0000E4 |
508363 | 90-M-042-NC-0-N-8-N-0-C3-W-00-NNN-00-00-E6 | 90M042NC0N8N0C3W00NNN0000E6 |
516503 | 90-M-042-NC-0-N-8-N-0-C3-W-00-NNN-00-00-F3 | 90M042NC0N8N0C3W00NNN0000F3 |
700427 | 90-M-042-NC-0-N-8-N-0-K4-W-00-EFA-00-00-F0 | 90M042NC0N8N0K4W00EFA0000F0 |
770354 | 90-M-042-NC-0-N-8-N-0-K4-W-00-NNN-00-00-F3 | 90M042NC0N8N0K4W00NNN0000F3 |
